INA GE60-SX Image 4
Visual product photo and picture of the product.
Price: 462.03 $
Specifications
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
95 |
| Width (B) MM |
23 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
3.7402 |
| Width (B) Inch |
0.9055 |
| Weight (kg) |
0.99 kg
|
Product Properties
| Seal |
No Seal |
| Contact Material |
Steel on Steel |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
95 |
| Height (T) mm |
23 |
| Radial Static Load Rating C0r (N) |
805000 |
| Radial Dynamic Load Rating Cr (N) |
161000 |
| Basic static load rating, radial (C 0r) |
"805000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Angular contact spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-2, open design |
Suffix description
| SX |
Angular Contact Spherical Plain Bearing Requiring Maintenance To Iso 12 2402, Mounting Dimensions As For Tapered Roller Bearings To Din 720, 320X, Sliding Contact Surface Steel/Steel |
