INA GE40-FW-2RS-A Image 5
Visual product photo and picture of the product.
Price: 108.37 $
Specifications
Weight and Dimensions
| Inner (d) MM |
40 |
| Outer (D) MM |
68 |
| Width (B) MM |
40 |
| Inner (d) Inch |
1.5748 |
| Outer (D) Inch |
2.6772 |
| Width (B) Inch |
1.5748 |
| Weight (kg) |
0.52 kg
|
Product Properties
| Seal |
2RS - Rubber Seal on Two Sides |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
68 |
| Radial Static Load Rating C0r (N) |
600000 |
| Width inner ring (B) mm |
40 |
| Radial Dynamic Load Rating Cr (N) |
360000 |
| Basic static load rating, radial (C 0r) |
"600000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Radial spherical plain bearing, maintenance-free, sliding layer: ELGOGLIDE, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series G, sealed |
Suffix description
| FW |
Sliding Contact Surface Hard Chromium/PTFE (Polyetrafluoroethylene) Composite, Wide Inner Ring |
| 2RS |
Lip Seals On Both Sides |
| A |
Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard) |
