INA GE35-FO-2RS-HLN Image 4
Visual product photo and picture of the product.
Price: 35.44 $
Specifications
Weight and Dimensions
| Inner (d) MM |
35 |
| Outer (D) MM |
62 |
| Width (B) MM |
35 |
| Inner (d) Inch |
1.378 |
| Outer (D) Inch |
2.4409 |
| Width (B) Inch |
1.378 |
| Weight (kg) |
0.39 kg
|
Product Properties
| Seal |
2RS - Rubber Seal on Two Sides |
| Contact Material |
Steel on Steel |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
62 |
| Radial Static Load Rating C0r (N) |
496000 |
| Width inner ring (B) mm |
35 |
| Radial Dynamic Load Rating Cr (N) |
99100 |
| Basic static load rating, radial (C 0r) |
"451000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Radial spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-1, dimension series G, sealed |
Suffix description
| FO |
Sliding Contact Surface Steel/Steel, Wider Inner Ring |
| 2RS |
Lip Seals On Both Sides |
| HLN |
Factory Location Code, No Additional Meaning, Can Be Used As Standard |
