INA GE30-XL-KRR-B-FA101 Image 3
Visual product photo and picture of the product.
Price: 153.91 $
Specifications
Weight and Dimensions
| Inner (d) MM |
30 |
| Outer (D) MM |
62 |
| Width (B) MM |
48,5 |
| Inner (d) Inch |
1.1811 |
| Outer (D) Inch |
2.4409 |
| Width (B) Inch |
1.9094 |
| Weight (kg) |
0.38 kg
|
Product Properties
| Seal |
2F - Standard Seal for Y-bearings |
| Lubrication |
Standard Lubrication |
| Special Treatment |
G - High/Low Tem Design -40/+180°C |
Data from Schaeffler (medias)
| Outside diameter (D SP) mm |
62 |
| Width (b) mm |
36,5 |
| Locking collar total width (B 1) mm |
48,5 |
| Radial Static Load Rating C0r (N) |
11300 |
| Radial Dynamic Load Rating Cr (N) |
20700 |
| Basic static load rating, radial (C 0r) |
"11300.0000" |
| ECLASS number |
23-05-08-02 |
| ECLASS2 number |
23-05-08-02 |
| Medias description |
Radial insert ball bearing GE..-XL-KRR-B-FA101 |
Suffix description
| XL |
X-Life |
| KRR |
Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B |
Bearing With Spherical Outer Ring |
| FA101 |
High And Low Temperature Design -40 ~ 180u2103 |
