INA GE30-SW-A Image 2
Visual product photo and picture of the product.
Price: 78.82 $
Specifications
Weight and Dimensions
| Inner (d) MM |
30 |
| Outer (D) MM |
55 |
| Width (B) MM |
17 |
| Inner (d) Inch |
1.1811 |
| Outer (D) Inch |
2.1654 |
| Width (B) Inch |
0.6693 |
| Weight (kg) |
0.1939 kg
|
Product Properties
| Seal |
No Seal |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
55 |
| Height (T) mm |
17 |
| Radial Static Load Rating C0r (N) |
323000 |
| Width inner ring (B) mm |
16 |
| Radial Dynamic Load Rating Cr (N) |
194000 |
| Basic static load rating, radial (C 0r) |
"323000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Angular contact spherical plain bearing, maintenance-free, DIN ISO 12240-2, inner ring curved surface with hard chromium coating, open design |
Suffix description
| SW |
Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene)) |
| A |
Schaeffler Internal Code, No Technical Meaning (Can Be Used As Standard) |
