INA GE120-UK-2TS Image 2
Visual product photo and picture of the product.
Price: 652.27 $
Specifications
Weight and Dimensions
| Inner (d) MM |
120 |
| Outer (D) MM |
180 |
| Width (B) MM |
85 |
| Inner (d) Inch |
4.7244 |
| Outer (D) Inch |
7.0866 |
| Width (B) Inch |
3.3465 |
| Weight (kg) |
7.9 kg
|
Product Properties
| Seal |
2TS - Double Teflon Seal |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
180 |
| Radial Static Load Rating C0r (N) |
4480000 |
| Width inner ring (B) mm |
85 |
| Radial Dynamic Load Rating Cr (N) |
2690000 |
| Basic static load rating, radial (C 0r) |
"4480000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Radial spherical plain bearing, maintenance-free, sliding layer: ELGOGLIDE, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series E, sealed |
Suffix description
| UK |
Sliding Contact Surface Hard Chromium/PTFE Composite |
| 2TS |
Two Teflon Seals Reinforced With Z-Shields |
