INA GE12-FW Image 3
Visual product photo and picture of the product.
Price: 35.30 $
Specifications
Weight and Dimensions
| Inner (d) MM |
12 |
| Outer (D) MM |
26 |
| Width (B) MM |
15 |
| Inner (d) Inch |
0.4724 |
| Outer (D) Inch |
1.0236 |
| Width (B) Inch |
0.5906 |
| Weight (kg) |
0.03 kg
|
Product Properties
| Seal |
No Seal |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
26 |
| Radial Static Load Rating C0r (N) |
44600 |
| Width inner ring (B) mm |
15 |
| Radial Dynamic Load Rating Cr (N) |
17800 |
| Basic static load rating, radial (C 0r) |
"44600.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Radial spherical plain bearing, maintenance-free, sliding layer: PTFE composite, inner ring curved surface with hard chromium coating DIN ISO 12240-1, dimension series G, open design |
Suffix description
| FW |
Sliding Contact Surface Hard Chromium/PTFE (Polyetrafluoroethylene) Composite, Wide Inner Ring |
