INA GE100-UK-2TS Image 6
Visual product photo and picture of the product.
Price: 418.43 $
Specifications
Weight and Dimensions
| Inner (d) MM |
100 |
| Outer (D) MM |
150 |
| Width (B) MM |
70 |
| Inner (d) Inch |
3.937 |
| Outer (D) Inch |
5.9055 |
| Width (B) Inch |
2.7559 |
| Weight (kg) |
4.3 kg
|
Product Properties
| Seal |
2TS - Double Teflon Seal |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
150 |
| Radial Static Load Rating C0r (N) |
2860000 |
| Width inner ring (B) mm |
70 |
| Radial Dynamic Load Rating Cr (N) |
1720000 |
| Basic static load rating, radial (C 0r) |
"2860000.0000" |
| ECLASS number |
23-05-01-06 |
| ECLASS2 number |
23-05-01-06 |
| Medias description |
Radial spherical plain bearing, maintenance-free, sliding layer: ELGOGLIDE, inner ring curved surface with hard chromium coating, DIN ISO 12240-1, dimension series E, sealed |
Suffix description
| UK |
Sliding Contact Surface Hard Chromium/PTFE Composite |
| 2TS |
Two Teflon Seals Reinforced With Z-Shields |
