INA GAL8-UK Image 3
Visual product photo and picture of the product.
Price: 23.52 $
Specifications
| Brand |
INA
|
| Item Number |
GAL8-UK INA
|
| Manufacturer Part Number |
0066427130000 |
| Also known as |
SAL8C
|
| EAN |
4012802528305 |
| Category |
Rod End
|
Weight and Dimensions
| Inner (d) MM |
8 |
| Outer (D) MM |
25 |
| Width (B) MM |
8 |
| Inner (d) Inch |
0.315 |
| Outer (D) Inch |
0.9843 |
| Width (B) Inch |
0.315 |
| Weight (kg) |
0.025 kg
|
Product Properties
| Seal |
No Seal |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
16 |
| Outer eye diameter (d 2) mm |
24 |
| Radial Static Load Rating C0r (N) |
12900 |
| Width inner ring (B) mm |
8 |
| Radial Dynamic Load Rating Cr (N) |
5850 |
| Basic static load rating, radial (C 0r) |
"12900.0000" |
| Total length external thread rod (l 2) mm |
54 |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Rod end with external thread, left hand thread, maintenance-free, sliding layer: PTFE composite, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, open design |
Suffix description
| UK |
Sliding Contact Surface Hard Chromium/PTFE Composite |
