INA GAL60-UK-2RS-A Image 3
Visual product photo and picture of the product.
Price: 588.57 $
Specifications
| Brand |
INA
|
| Item Number |
GAL60-UK-2RS-A INA
|
| Manufacturer Part Number |
0066465490000 |
| Also known as |
SALA60TE-2RS
|
| EAN |
4012802529135 |
| Category |
Rod End
|
Weight and Dimensions
| Inner (d) MM |
60 |
| Outer (D) MM |
137 |
| Width (B) MM |
44 |
| Inner (d) Inch |
2.3622 |
| Outer (D) Inch |
5.3937 |
| Width (B) Inch |
1.7323 |
| Weight (kg) |
6.25 kg
|
Product Properties
| Seal |
2RS - Rubber Seal on Two Sides |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
90 |
| Outer eye diameter (d 2) mm |
135 |
| Radial Static Load Rating C0r (N) |
485000 |
| Width inner ring (B) mm |
44 |
| Radial Dynamic Load Rating Cr (N) |
691000 |
| Basic static load rating, radial (C 0r) |
"485000.0000" |
| Total length external thread rod (l 2) mm |
277,5 |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Rod end with external thread, left hand thread, maintenance-free, sliding layer: ELGOGLIDE, DIN ISO 12240-4, dimension series E, type M, inner ring curved surface with hard chromium coating, sealed |
Suffix description
| UK |
Sliding Contact Surface Hard Chromium/PTFE Composite |
| 2RS |
Lip Seals On Both Sides |
| A |
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
