INA GAKSR16-PS Image 4
Visual product photo and picture of the product.
Price: 158.06 $
Specifications
Weight and Dimensions
| Inner (d) MM |
16 |
| Outer (D) MM |
43 |
| Width (B) MM |
21 |
| Inner (d) Inch |
0.6299 |
| Outer (D) Inch |
1.6929 |
| Width (B) Inch |
0.8268 |
| Weight (kg) |
0.19 kg
|
Product Properties
| Seal |
No Seal |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
32 |
| Outer eye diameter (d 2) mm |
43 |
| Radial Static Load Rating C0r (N) |
19000 |
| Width inner ring (B) mm |
21 |
| Radial Dynamic Load Rating Cr (N) |
39000 |
| Basic static load rating, radial (C 0r) |
"19000.0000" |
| Total length external thread rod (l 2) mm |
87,5 |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Corrosion-resistant rod end, with external thread, right hand thread, maintenance-free, sliding layer: PTFE film, DIN ISO 12240-4, dimension series K, type F, open design |
Suffix description
| PS |
Special Steel, Maintenance Free |
