INA GAKSR14-PS Image 2
Visual product photo and picture of the product.
Price: 146.19 $
Specifications
Weight and Dimensions
| Inner (d) MM |
14 |
| Outer (D) MM |
37 |
| Width (B) MM |
19 |
| Inner (d) Inch |
0.5512 |
| Outer (D) Inch |
1.4567 |
| Width (B) Inch |
0.748 |
| Weight (kg) |
0.13 kg
|
Product Properties
| Seal |
No Seal |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
28 |
| Outer eye diameter (d 2) mm |
37 |
| Radial Static Load Rating C0r (N) |
13700 |
| Width inner ring (B) mm |
19 |
| Radial Dynamic Load Rating Cr (N) |
31000 |
| Basic static load rating, radial (C 0r) |
"13700.0000" |
| Total length external thread rod (l 2) mm |
78,5 |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Corrosion-resistant rod end, with external thread, right hand thread, maintenance-free, sliding layer: PTFE film, DIN ISO 12240-4, dimension series K, type F, open design |
Suffix description
| PS |
Special Steel, Maintenance Free |
