INA GAKR16-PW Image 4
Visual product photo and picture of the product.
Price: 42.86 $
Specifications
| Brand |
INA
|
| Item Number |
GAKR16-PW INA
|
| Manufacturer Part Number |
0066335280000 |
| Also known as |
SAKB16F
|
| EAN |
4012802524307 |
| Category |
Rod End
|
Weight and Dimensions
| Inner (d) MM |
16 |
| Outer (D) MM |
42 |
| Width (B) MM |
21 |
| Inner (d) Inch |
0.6299 |
| Outer (D) Inch |
1.6535 |
| Width (B) Inch |
0.8268 |
| Weight (kg) |
0.201 kg
|
Product Properties
| Seal |
No Seal |
| Contact Material |
Steel on PTFE |
Data from Schaeffler (medias)
| Outside diameter bearing (D) mm |
32 |
| Outer eye diameter (d 2) mm |
42 |
| Radial Static Load Rating C0r (N) |
45300 |
| Width inner ring (B) mm |
21 |
| Radial Dynamic Load Rating Cr (N) |
38600 |
| Basic static load rating, radial (C 0r) |
"45300.0000" |
| Total length external thread rod (l 2) mm |
87 |
| ECLASS number |
23-05-01-05 |
| ECLASS2 number |
23-05-01-05 |
| Medias description |
Rod end GAKR..-PW, external threads, maintenance-free |
Suffix description
| PW |
Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film |
