INA E50-XL-KLL-ID+21+10 Image 2
Visual product photo and picture of the product.
Price: 69.78 $
Specifications
Weight and Dimensions
| Inner (d) MM |
50 |
| Outer (D) MM |
90 |
| Width (B) MM |
62,8 |
| Inner (d) Inch |
1.9685 |
| Outer (D) Inch |
3.5433 |
| Width (B) Inch |
2.4724 |
| Weight (kg) |
1 kg
|
Product Properties
| Seal |
2L - LS-seal at Both Sides |
| Lubrication |
Standard Lubrication |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
49,2 |
| Locking collar total width (B 1) mm |
62,8 |
| Radial Static Load Rating C0r (N) |
23200 |
| Radial Dynamic Load Rating Cr (N) |
37500 |
| Basic static load rating, radial (C 0r) |
"23200.0000" |
| ECLASS number |
23-05-08-02 |
| ECLASS2 number |
23-05-08-02 |
| Medias description |
Radial insert ball bearings E..-KLL, cylindrical outer ring, location by eccentric locking collar, L seals on both sides |
Suffix description
| XL |
X-Life |
| K |
Conrad (Non-Filling Slot) Type |
| LL |
Labyrinth Seals On Both Sides (L Type Seal - All Parts Of The L Type Seal Are Zinc Plated On All Sides In Order To Improve Corrosion Protection - No Seal Friction) |
| B |
Bearing With Spherical Outer Ring |
| ID+21+10 |
Inner Ring Tolerance In Micron |
