INA E40-XL-KLL bearing image 3
INA E40-XL-KLL bearing image 1
INA E40-XL-KLL bearing image 2
INA E40-XL-KLL bearing image 3
INA E40-XL-KLL bearing image 4
INA E40-XL-KLL bearing image 5
Price: 49.07 $
Specifications
Brand INA
Item Number E40-XL-KLL INA
Manufacturer Part Number 0008522010000
Also known as E40-KLL
EAN 4012802799934
Category Bearings for Housings
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 80
Width (B) MM 56,5
Inner (d) Inch 1.5748
Outer (D) Inch 3.1496
Width (B) Inch 2.2244
Weight (kg) 0.74 kg
Product Properties
Seal 2L - LS-seal at Both Sides
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 42,9
Locking collar total width (B 1) mm 56,5
Radial Static Load Rating C0r (N) 19800
Radial Dynamic Load Rating Cr (N) 34500
Basic static load rating, radial (C 0r) "19800.0000"
ECLASS number 23-05-08-02
ECLASS2 number 23-05-08-02
Medias description Radial insert ball bearings E..-KLL, cylindrical outer ring, location by eccentric locking collar, L seals on both sides
Suffix description
XL X-Life
KRR Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
