Price: 29.77 $
Specifications
Brand INA
Item Number E30-XL-KRR INA
Manufacturer Part Number 0008049750000
Also known as E30-KRR
EAN 4012802783667
Category Bearings for Housings
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 62
Width (B) MM 48,5
Inner (d) Inch 1.1811
Outer (D) Inch 2.4409
Width (B) Inch 1.9094
Weight (kg) 0.38 kg
Product Properties
Seal 2RS - Rubber Seal on Two Sides
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 36,5
Locking collar total width (B 1) mm 48,5
Radial Static Load Rating C0r (N) 11300
Radial Dynamic Load Rating Cr (N) 20700
Basic static load rating, radial (C 0r) "11300.0000"
ECLASS number 23-05-08-02
ECLASS2 number 23-05-08-02
Medias description Radial insert ball bearings E..-KRR, cylindrical outer ring, location by eccentric locking collar, R seals on both sides
Suffix description
XL X-Life
KRR Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
