INA CSXA020-2RS-HLE Image 4
Visual product photo and picture of the product.
Price: 545.41 $
Specifications
Weight and Dimensions
| Inner (d) MM |
50,8 |
| Outer (D) MM |
63,5 |
| Width (B) MM |
6,35 |
| Inner (d) Inch |
2 |
| Outer (D) Inch |
2.5 |
| Width (B) Inch |
0.25 |
| Weight (kg) |
0.05 kg
|
Product Properties
| Seal |
2RS - Rubber Seal on Two Sides |
| Cage Type |
Y - Pressed Brass Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
ABEC.1 Tolerances |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Data from Schaeffler (medias)
| Width (b) mm |
6,35 |
| Radial Static Load Rating C0r (N) |
4600 |
| Radial Dynamic Load Rating Cr (N) |
4400 |
| Basic static load rating, radial (C 0r) |
"4600.0000" |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Thin Section Bearing CSXA..-2RS, four-point contact bearing |
Suffix description
| 2RS |
Rubber Seals At Each Side Of The Bearing |
| HLE |
Factory Location Code, No Additional Meaning. Can Be Used As Standard |
