INA CSEAA010-TV-HLE Image 4
Visual product photo and picture of the product.
Price: 327.58 $
Specifications
Weight and Dimensions
| Inner (d) MM |
25,4 |
| Outer (D) MM |
34,925 |
| Width (B) MM |
4,7625 |
| Inner (d) Inch |
1 |
| Outer (D) Inch |
1.375 |
| Width (B) Inch |
0.1875 |
| Weight (kg) |
0.01 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
P - Plastic Molded Cage |
| Precision |
Standard Precision |
| Contact Angle |
30 degrees |
| Pairing |
No pairing |
| Axial Internal Clearance / Preload |
No Preload |
| Lubrication |
Standard Lubrication |
Data from Schaeffler (medias)
| Width (b) mm |
4,763 |
| Radial Static Load Rating C0r (N) |
1260 |
| Radial Dynamic Load Rating Cr (N) |
1780 |
| Basic static load rating, radial (C 0r) |
"1260.0000" |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Thin Section Bearing CSEAA..-TV, angular contact ball bearing |
Suffix description
| TV |
Solid Cage Of Glass-Fibre Reinforced Polyamide, Ball Riding |
| HLE |
Factory Location Code, No Additional Meaning. Can Be Used As Standard |
