INA BK2016-AS1 Image 4
Visual product photo and picture of the product.
Price: 6.59 $
Specifications
Weight and Dimensions
| Inner (d) MM |
20 |
| Outer (D) MM |
26 |
| Width (B) MM |
16 |
| Inner (d) Inch |
0.7874 |
| Outer (D) Inch |
1.0236 |
| Width (B) Inch |
0.6299 |
| Weight (kg) |
0.024 kg
|
Product Properties
Data from Schaeffler (medias)
| Under roller diameter (F w) mm |
20 |
| Basic static load rating, radial (C 0r) |
20100 |
| Limiting speed (n G) |
12700 |
| Limiting speed for grease lubrication (n G Grease) |
7600 |
| Reference speed (n u03d1r) |
9300 |
| ECLASS number |
23-05-09-06 |
| ECLASS2 number |
23-05-09-06 |
Suffix description
| AS1 |
Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes |
