INA AXK160200-A/0-10 Image 3
Visual product photo and picture of the product.
Price: 95.30 $
Specifications
Weight and Dimensions
| Inner (d) MM |
160 |
| Outer (D) MM |
200 |
| Width (B) MM |
5 |
| Inner (d) Inch |
6.2992 |
| Outer (D) Inch |
7.874 |
| Width (B) Inch |
0.1969 |
| Weight (kg) |
0.25 kg
|
Data from Schaeffler (medias)
| Outside diameter (D c) mm |
200 |
| Rolling element diameter (D W) mm |
5 |
| Axial Static Load Rating C0a (N) |
1020000 |
| Axial Dynamic Load Rating Ca (N) |
148000 |
| Limiting speed (n G) |
1600 |
| Raceway dimension (E a) mm |
197 |
| Raceway dimension (E b) mm |
166 |
| Reference speed (n u03d1r) |
620 |
| ECLASS number |
23-05-11-90 |
| ECLASS2 number |
23-05-11-90 |
| Medias description |
Axial needle roller and cage assemblies, single direction, to DIN 5405-2 |
Suffix description
| A |
The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307) |
| /0-10 |
Micron - Needle Sort |
