INA AXK0515-TV/0-10 Image 2
Visual product photo and picture of the product.
Price: 2.39 $
Specifications
Weight and Dimensions
| Inner (d) MM |
5 |
| Outer (D) MM |
15 |
| Width (B) MM |
2 |
| Inner (d) Inch |
0.1969 |
| Outer (D) Inch |
0.5906 |
| Width (B) Inch |
0.0787 |
| Weight (kg) |
0.001 kg
|
Data from Schaeffler (medias)
| Outside diameter (D c) mm |
15 |
| Rolling element diameter (D W) mm |
2 |
| Axial Static Load Rating C0a (N) |
9200 |
| Axial Dynamic Load Rating Ca (N) |
4750 |
| Limiting speed (n G) |
20500 |
| Raceway dimension (E a) mm |
14 |
| Raceway dimension (E b) mm |
6 |
| Reference speed (n u03d1r) |
13000 |
| ECLASS number |
23-05-11-90 |
| ECLASS2 number |
23-05-11-90 |
| Medias description |
Axial needle roller and cage assemblies, single direction, to DIN 5405-2 |
Suffix description
| TV |
Solid Cage Of Glass-Fibre Reinforced Polyamide, Ball Riding |
| /0-10 |
Micron - Needle Sort |
