INA 61924-MA-HLU-C3 Image 3
Visual product photo and picture of the product.
Price: 445.05 $
Specifications
Weight and Dimensions
| Inner (d) MM |
120 |
| Outer (D) MM |
165 |
| Width (B) MM |
22 |
| Inner (d) Inch |
4.7244 |
| Outer (D) Inch |
6.4961 |
| Width (B) Inch |
0.8661 |
| Weight (kg) |
1.2 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
22 |
| Basic static load rating, radial (C 0r) |
57000 |
| Limiting speed (n G) |
7100 |
| Reference speed (n u03d1r) |
4150 |
Suffix description
| MA |
Machined Brass Cage, Outer Ring Guided |
| HLU |
Factory Location Code, No Additional Meaning, Can Be Used As Standard |
| C3 |
Internal Clearance Larger Than Normal |
