INA 3904-2RS

Specifications

Brand	INA
Item Number	3904-2RS INA
Manufacturer Part Number	0008133620000
EAN	4012802029284
Category	Angular Contact Ball Bearing Double Row

Weight and Dimensions

Inner (d) MM	20
Outer (D) MM	37
Width (B) MM	13
Inner (d) Inch	0.7874
Outer (D) Inch	1.4567
Width (B) Inch	0.5118
Weight (kg)	0.005 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	2RS - Rubber Seal on Two Sides
Cage Type	S - Steel or Standard Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Standard

Data from Schaeffler (medias)

Width (b) mm	13
Radial Static Load Rating C0r (N)	6800
Radial Dynamic Load Rating Cr (N)	9100
Basic static load rating, radial (C 0r)	"6800.0000"
Limiting speed (n G)	10300
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03
Medias description	Angular contact ball bearing 39..-B-2RS-TVH, double row, 1 inner ring

Suffix description

2RS	Lip Seal At Both Sides Of The Bearing, Axial Fitting
