INA 3903-2RS-C3

Specifications

Brand	INA
Item Number	3903-2RS-C3 INA
Manufacturer Part Number	0038276580030
EAN	4054366154910
Category	Angular Contact Ball Bearing Double Row

Weight and Dimensions

Inner (d) MM	17
Outer (D) MM	30
Width (B) MM	10
Inner (d) Inch	0.6693
Outer (D) Inch	1.1811
Width (B) Inch	0.3937
Weight (kg)	0.026 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	2RS - Rubber Seal on Two Sides
Cage Type	S - Steel or Standard Cage
External Modification	No External Modification
Radial Internal Play	C3 Internal Play (Higher than Cn)
Precision	Standard Precision
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Standard

Data from Schaeffler (medias)

Width (b) mm	10
Radial Static Load Rating C0r (N)	4100
Radial Dynamic Load Rating Cr (N)	5200
Basic static load rating, radial (C 0r)	"4100.0000"
Limiting speed (n G)	13300
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03
Medias description	Angular contact ball bearing 39..-B-2RSR-TVH, double row, 1 inner ring

Suffix description

2RS	Lip Seal At Both Sides Of The Bearing, Axial Fitting
C3	Internal Clearance Larger Than Normal
