INA 3816-2Z-C3

Specifications

Brand	INA
Item Number	3816-2Z-C3 INA
Manufacturer Part Number	0009722660030
EAN	4054365729386
Category	Angular Contact Ball Bearing Double Row

Weight and Dimensions

Inner (d) MM	80
Outer (D) MM	100
Width (B) MM	15
Weight (kg)	0.22 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	ZZ/2Z - Steel Seal on Two Sides
Cage Type	P - Plastic Molded Cage
External Modification	No External Modification
Radial Internal Play	C3 Internal Play (Higher than Cn)
Precision	Standard Precision
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Standard

Data from Schaeffler (medias)

Width (b) mm	15
Basic static load rating, radial (C 0r)	24800
Limiting speed (n G)	5100
Reference speed (n u03d1r)	3650

Suffix description

2Z	Gap Seals At Both Sides Of The Bearing
C3	Internal Clearance Larger Than Normal
