INA 3816-2Z

Specifications

Brand	INA
Item Number	3816-2Z INA
Manufacturer Part Number	0009722660000
EAN	4012802029253
Category	Angular Contact Ball Bearing Double Row

Weight and Dimensions

Inner (d) MM	80
Outer (D) MM	100
Width (B) MM	15
Inner (d) Inch	3.1496
Outer (D) Inch	3.937
Width (B) Inch	0.5906
Weight (kg)	0.22 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	ZZ/2Z - Steel Seal on Two Sides
Cage Type	P - Plastic Molded Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Standard

Data from Schaeffler (medias)

Width (b) mm	15
Radial Static Load Rating C0r (N)	24800
Radial Dynamic Load Rating Cr (N)	19200
Basic static load rating, radial (C 0r)	"24800.0000"
Limiting speed (n G)	5100
Reference speed (n u03d1r)	3650
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03
Medias description	Angular contact ball bearing 38..-B-2RZ-TVH, double row, 1 inner ring

Suffix description

2Z	Gap Seals At Both Sides Of The Bearing
