INA 3814-2Z Image 2
Visual product photo and picture of the product.
Price: 104.02 $
Specifications
Weight and Dimensions
| Inner (d) MM |
70 |
| Outer (D) MM |
90 |
| Width (B) MM |
15 |
| Inner (d) Inch |
2.7559 |
| Outer (D) Inch |
3.5433 |
| Width (B) Inch |
0.5906 |
| Weight (kg) |
0.205 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
ZZ/2Z - Steel Seal on Two Sides |
| Cage Type |
P - Plastic Molded Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Data from Schaeffler (medias)
| Width (b) mm |
15 |
| Radial Static Load Rating C0r (N) |
23200 |
| Radial Dynamic Load Rating Cr (N) |
18800 |
| Basic static load rating, radial (C 0r) |
"23200.0000" |
| Limiting speed (n G) |
5700 |
| Reference speed (n u03d1r) |
4050 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 38..-B-2RZ-TVH, double row, 1 inner ring |
