INA 3814-2RS

Specifications

Brand	INA
Item Number	3814-2RS INA
Manufacturer Part Number	0009722310000
EAN	4012802126082
Category	Angular Contact Ball Bearing Double Row

Weight and Dimensions

Inner (d) MM	70
Outer (D) MM	90
Width (B) MM	15
Inner (d) Inch	2.7559
Outer (D) Inch	3.5433
Width (B) Inch	0.5906
Weight (kg)	0.205 kg

Product Properties

Bore	C - Cylindrical Bore
Seal	2RS - Rubber Seal on Two Sides
Cage Type	P - Plastic Molded Cage
External Modification	No External Modification
Radial Internal Play	Cn Normal Internal Play
Precision	Standard Precision
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring	Standard

Data from Schaeffler (medias)

Width (b) mm	15
Radial Static Load Rating C0r (N)	23200
Radial Dynamic Load Rating Cr (N)	18800
Basic static load rating, radial (C 0r)	"23200.0000"
Limiting speed (n G)	3450
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03
Medias description	Angular contact ball bearings 38..-B-2RS, Double row design, lip seals on both sides, contact angle a = 25°

Suffix description

2RS	Lip Seal At Both Sides Of The Bearing, Axial Fitting
