INA 3807-2Z Image 3
Visual product photo and picture of the product.
Price: 42.21 $
Specifications
Weight and Dimensions
| Inner (d) MM |
35 |
| Outer (D) MM |
47 |
| Width (B) MM |
10 |
| Inner (d) Inch |
1.378 |
| Outer (D) Inch |
1.8504 |
| Width (B) Inch |
0.3937 |
| Weight (kg) |
0.036 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
ZZ/2Z - Steel Seal on Two Sides |
| Cage Type |
P - Plastic Molded Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Data from Schaeffler (medias)
| Width (b) mm |
10 |
| Radial Static Load Rating C0r (N) |
6800 |
| Radial Dynamic Load Rating Cr (N) |
6500 |
| Basic static load rating, radial (C 0r) |
"6800.0000" |
| Limiting speed (n G) |
11700 |
| Reference speed (n u03d1r) |
7400 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearing 38..-B-2RZ-TVH, double row, 1 inner ring |
Suffix description
| 2Z |
Gap Seals At Both Sides Of The Bearing |
