INA 3217-2Z Image 4
Visual product photo and picture of the product.
Price: 271.44 $
Specifications
Weight and Dimensions
| Inner (d) MM |
85 |
| Outer (D) MM |
150 |
| Width (B) MM |
49,2 |
| Inner (d) Inch |
3.3465 |
| Outer (D) Inch |
5.9055 |
| Width (B) Inch |
1.937 |
| Weight (kg) |
3.32 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
ZZ/2Z - Steel Seal on Two Sides |
| Cage Type |
P - Plastic Molded Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Data from Schaeffler (medias)
| Width (b) mm |
49,2 |
| Radial Static Load Rating C0r (N) |
127000 |
| Radial Dynamic Load Rating Cr (N) |
135000 |
| Basic static load rating, radial (C 0r) |
"127000.0000" |
| Limiting speed (n G) |
3350 |
| Reference speed (n u03d1r) |
4900 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearings 32..-B-2Z, main dimensions to DIN 628-3, double row, gap seals on both sides, contact angle a = 25° |
Suffix description
| 2Z |
Gap Seals At Both Sides Of The Bearing |
