INA 3006-C3 Image 4
Visual product photo and picture of the product.
Price: 45.19 $
Specifications
Weight and Dimensions
| Inner (d) MM |
30 |
| Outer (D) MM |
55 |
| Width (B) MM |
19 |
| Inner (d) Inch |
1.1811 |
| Outer (D) Inch |
2.1654 |
| Width (B) Inch |
0.748 |
| Weight (kg) |
0.16 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
P - Plastic Molded Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Standard |
Data from Schaeffler (medias)
| Width (b) mm |
19 |
| Radial Static Load Rating C0r (N) |
15400 |
| Radial Dynamic Load Rating Cr (N) |
19900 |
| Basic static load rating, radial (C 0r) |
"15400.0000" |
| Limiting speed (n G) |
13500 |
| Reference speed (n u03d1r) |
10100 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Angular contact ball bearings 30..-B, double row, contact angle a = 25° |
Suffix description
| C3 |
Internal Clearance Larger Than Normal |
