INA 204-XL-KRR

INA 204-XL-KRR
INA 204-XL-KRR rulman resim 1
INA 204-XL-KRR rulman resim 2
INA 204-XL-KRR rulman resim 3
INA 204-XL-KRR rulman resim 4
INA 204-XL-KRR rulman resim 5
Price: 16.19 $
Specifications
Brand INA
Item Number 204-XL-KRR INA
Manufacturer Part Number 0008092250000
Also known as 204-KRR
EAN 4012802783285
Category Bearings for Housings
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 47
Width (B) MM 14
Inner (d) Inch 0.7874
Outer (D) Inch 1.8504
Width (B) Inch 0.5512
Weight (kg) 0.1 kg
Product Properties
Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 17,7
Radial Static Load Rating C0r (N) 6600
Radial Dynamic Load Rating Cr (N) 13600
Basic static load rating, radial (C 0r) "6600.0000"
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Radial insert ball bearings 2..-KRR, cylindrical outer ring, inner ring for fit, R seals on both sides
Suffix description
XL X-Life
KRR Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
