FAG 6204-C-HRS

FAG 6204-C-HRS
FAG 6204-C-HRS rulman resim 1
FAG 6204-C-HRS rulman resim 2
FAG 6204-C-HRS rulman resim 3
FAG 6204-C-HRS rulman resim 4
Price: 4.80 $
Specifications
Brand FAG
Item Number 6204-C-HRS FAG
Manufacturer Part Number 0954045460000
Also known as 6204-HRS
EAN 4064327040411
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 47
Width (B) MM 14
Inner (d) Inch 0.7874
Outer (D) Inch 1.8504
Width (B) Inch 0.5512
Weight (kg) 0.1031 kg
Product Properties
Bore C - Cylindrical Bore
Seal RH - High Speed Low Friction Seal on One Side
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 14
Radial Static Load Rating C0r (N) 6600
Radial Dynamic Load Rating Cr (N) 13900
Basic static load rating, radial (C 0r) "6600.0000"
Limiting speed (n G) 14500
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 62..-C-HRS, single row, cf. DIN 625-1
Suffix description
C Deep Groove Ball Bearings Of Generation C, Modified Internal Construction
HRS High Speed/Low Friction Seal
