INA 203-XL-KRR Image 4
Visual product photo and picture of the product.
Price: 14.78 $
Specifications
Weight and Dimensions
| Inner (d) MM |
17 |
| Outer (D) MM |
40 |
| Width (B) MM |
18,3 |
| Inner (d) Inch |
0.6693 |
| Outer (D) Inch |
1.5748 |
| Width (B) Inch |
0.7205 |
| Weight (kg) |
0.09 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
2RS - Rubber Seal on Two Sides |
| Cage Type |
S - Steel or Standard Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Lubrication |
Standard Lubrication |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment |
No Special Treatment |
Data from Schaeffler (medias)
| Width (b) mm |
18,3 |
| Radial Static Load Rating C0r (N) |
4750 |
| Radial Dynamic Load Rating Cr (N) |
10100 |
| Basic static load rating, radial (C 0r) |
"4750.0000" |
| ECLASS number |
23-05-08-01 |
| ECLASS2 number |
23-05-08-01 |
| Medias description |
Radial insert ball bearings 2..-KRR, cylindrical outer ring, inner ring for fit, R seals on both sides |
Suffix description
| XL |
X-Life |
| KRR |
Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
