INA 202-XL-KRR Image 6

Visual product photo and picture of the product.

INA 202-XL-KRR bearing image 6
INA 202-XL-KRR bearing image 1
INA 202-XL-KRR bearing image 2
INA 202-XL-KRR bearing image 3
INA 202-XL-KRR bearing image 4
INA 202-XL-KRR bearing image 5
INA 202-XL-KRR bearing image 6
Price: 12.58 $
Specifications
Brand INA
Item Number 202-XL-KRR INA
Manufacturer Part Number 0008072060000
Also known as 202-KRR
EAN 4012802783582
Category Bearings for Housings
Weight and Dimensions
Inner (d) MM 15
Outer (D) MM 35
Width (B) MM 14,4
Inner (d) Inch 0.5906
Outer (D) Inch 1.378
Width (B) Inch 0.5669
Weight (kg) 0.05 kg
Product Properties
Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 14,4
Radial Static Load Rating C0r (N) 3700
Radial Dynamic Load Rating Cr (N) 8100
Basic static load rating, radial (C 0r) "3700.0000"
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Radial insert ball bearings 2..-KRR, cylindrical outer ring, inner ring for fit, R seals on both sides
Suffix description
XL X-Life
KRR Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
