GMN Paul Müller Industrie S61916E TA P4 UL GMN Paul Müller Industrie Image 2

Visual product photo and picture of the product.

GMN Paul Müller Industrie S61916E TA P4 UL GMN Paul Müller Industrie bearing image 2
GMN Paul Müller Industrie S61916E TA P4 UL GMN Paul Müller Industrie bearing image 1
GMN Paul Müller Industrie S61916E TA P4 UL GMN Paul Müller Industrie bearing image 2
Price: 292.42 $
Specifications
Brand GMN Paul Müller Industrie
Item Number S61916E TA P4 UL GMN Paul Müller Industrie
Also known as 71916ACDGA/P4A
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 80
Outer (D) MM 110
Width (B) MM 16
Inner (d) Inch 3.1496
Outer (D) Inch 4.3307
Width (B) Inch 0.6299
Weight (kg) 0.37 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4 Precision (Higher than P5)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload GA - Light Preload
Lubrication Standard Lubrication
Suffix description
E 25° Contact Angle
TA Laminated Phenolic Resin Cage Or Polyamide Cage Guided On Outer Ring
P4 Dimensional & Running Accuracy To ISO Tolerance Class 4 (More Accurate Than P5)-Abec.7
UL Single Bearing, Universally Ground, Light Preload
