GMN Paul Müller Industrie S61900E TA P4 UL GMN Paul Müller Industrie Image 2
Visual product photo and picture of the product.
Price: 83.69 $
Specifications
Weight and Dimensions
| Inner (d) MM |
10 |
| Outer (D) MM |
22 |
| Width (B) MM |
6 |
| Inner (d) Inch |
0.3937 |
| Outer (D) Inch |
0.8661 |
| Width (B) Inch |
0.2362 |
| Weight (kg) |
0.009 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
P4 Precision (Higher than P5) |
| Contact Angle |
25 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
GA - Light Preload |
| Lubrication |
Standard Lubrication |
Suffix description
| E |
25° Contact Angle |
| TA |
Laminated Phenolic Resin Cage Or Polyamide Cage Guided On Outer Ring |
| P4 |
Dimensional & Running Accuracy To ISO Tolerance Class 4 (More Accurate Than P5)-Abec.7 |
| UL |
Single Bearing, Universally Ground, Light Preload |
