GMN Paul Müller Industrie S6020E TA P4 UL GMN Paul Müller Industrie Image 2

Visual product photo and picture of the product.

Price: 460.57 $

Specifications

Brand	GMN Paul Müller Industrie
Item Number	S6020E TA P4 UL GMN Paul Müller Industrie
Also known as	7020ACDGA/P4A
Category	Angular Contact Ball Bearing Single Row

Weight and Dimensions

Inner (d) MM	100
Outer (D) MM	150
Width (B) MM	24
Inner (d) Inch	3.937
Outer (D) Inch	5.9055
Width (B) Inch	0.9449
Weight (kg)	1.25 kg

Product Properties

Seal	No Seal
Cage Type	TB - Hard Fiber Cage
Precision	P4 Precision (Higher than P5)
Contact Angle	25 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	GA - Light Preload
Lubrication	Standard Lubrication

Suffix description

E	25° Contact Angle
TA	Laminated Phenolic Resin Cage Or Polyamide Cage Guided On Outer Ring
P4	Dimensional & Running Accuracy To ISO Tolerance Class 4 (More Accurate Than P5)-Abec.7
UL	Single Bearing, Universally Ground, Light Preload
