GMN Paul Müller Industrie HYKH61908 2RZ E TA P4 UL GMN Paul Müller Industrie Image 3

Visual product photo and picture of the product.

GMN Paul Müller Industrie HYKH61908 2RZ E TA P4 UL GMN Paul Müller Industrie bearing image 3
GMN Paul Müller Industrie HYKH61908 2RZ E TA P4 UL GMN Paul Müller Industrie bearing image 1
GMN Paul Müller Industrie HYKH61908 2RZ E TA P4 UL GMN Paul Müller Industrie bearing image 2
GMN Paul Müller Industrie HYKH61908 2RZ E TA P4 UL GMN Paul Müller Industrie bearing image 3
Price: 368.11 $
Specifications
Brand GMN Paul Müller Industrie
Item Number HYKH61908 2RZ E TA P4 UL GMN Paul Müller Industrie
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 62
Width (B) MM 12
Inner (d) Inch 1.5748
Outer (D) Inch 2.4409
Width (B) Inch 0.4724
Weight (kg) 0.11 kg
Product Properties
Seal 2RZ - Rubber and Steel Seal
Cage Type TB - Hard Fiber Cage
Precision Hybrid Bearing + P4
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload GA - Light Preload
Lubrication Standard Lubrication
Suffix description
2RZ Ball Bearing To DIN 623, Two Low Friction (Gap) Seals
E 25° Contact Angle
TA Laminated Phenolic Resin Cage Or Polyamide Cage Guided On Outer Ring
P4 Is Equivalent To P4S According To DIN 628-6
UL Universal Matching - Light Preload
