FAG XCB71916-EDLR-T-P4S-K5-UL Image 3
Visual product photo and picture of the product.
Price: 1,602.88 $
Specifications
Weight and Dimensions
| Inner (d) MM |
80 |
| Outer (D) MM |
110 |
| Width (B) MM |
16 |
| Inner (d) Inch |
3.1496 |
| Outer (D) Inch |
4.3307 |
| Width (B) Inch |
0.6299 |
| Weight (kg) |
0.31 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
K5 - P4S + K5 |
| Contact Angle |
25 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication |
DLR |
Suffix description
| E |
25° Contact Angle |
| DLR |
Direct Lube, Integral O-Ring |
| T |
Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S-K5 |
Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter) |
| UL |
Single Bearing, Universal, Light Preload |
