FAG XC7009-E-TX-P4S-H145A-UL Image 2
Visual product photo and picture of the product.
Price: 734.41 $
Specifications
Weight and Dimensions
| Inner (d) MM |
45 |
| Outer (D) MM |
75 |
| Width (B) MM |
16 |
| Inner (d) Inch |
1.7717 |
| Outer (D) Inch |
2.9528 |
| Width (B) Inch |
0.6299 |
| Weight (kg) |
0.26 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
TB - Hard Fiber Cage |
| Precision |
P4S Precision (Higher than P4) |
| Contact Angle |
25 degrees |
| Pairing |
G - Universal Pairing |
| Axial Internal Clearance / Preload |
UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication |
Standard Lubrication |
Suffix description
| E |
25° Contact Angle |
| TX |
Textile Laminated Phenolic Resin, Outer Ring Guided. Modified Cage Design And Lubricant Flow Allow The FAG TX Spindle Bearings To Run Up To 10% Cooler Even In The High Speed Range |
| P4S |
Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| H145A |
Unknown |
| UL |
Single Bearing, Universal, Light Preload |
