FAG WS22215-E1-XL-K-2RSR Image 3
Visual product photo and picture of the product.
Price: 166.55 $
Specifications
Weight and Dimensions
| Inner (d) MM |
75 |
| Outer (D) MM |
130 |
| Width (B) MM |
38 |
| Inner (d) Inch |
2.9528 |
| Outer (D) Inch |
5.1181 |
| Width (B) Inch |
1.4961 |
| Weight (kg) |
2.1 kg
|
Product Properties
| Bore |
K - 1:12 Tapered Bore (Standard for Most Types) |
| Lubrication Enhancement |
W33 - Lubrication Groove and 3 Holes |
| Seal |
2RS - Rubber Seal on Two Sides |
| Cage Type |
S - Steel or Standard Cage |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution |
Non Vibrating Screen Execution |
Data from Schaeffler (medias)
| Width (b) mm |
38 |
| Radial Static Load Rating C0r (N) |
237000 |
| Radial Dynamic Load Rating Cr (N) |
216000 |
| Basic static load rating, radial (C 0r) |
"237000.0000" |
| Limiting speed (n G) |
1630 |
| ECLASS number |
23-05-09-11 |
| ECLASS2 number |
23-05-09-11 |
| Medias description |
Spherical roller bearing WS222..-E1-XL-K-2RSR, symmetric with cage guidance ring |
Suffix description
| E1 |
Increased Capacity Design |
| XL |
X-Life |
| K |
Tapered Bore, Taper 1:12 |
| 2RSR |
Rubber Seals At Each Side Of The Bearing |
