FAG RNU313-E-XL-TVP2 Image 2
Visual product photo and picture of the product.
Price: 134.08 $
Specifications
Weight and Dimensions
| Inner (d) MM |
83,5 |
| Outer (D) MM |
140 |
| Width (B) MM |
33 |
| Inner (d) Inch |
3.2874 |
| Outer (D) Inch |
5.5118 |
| Width (B) Inch |
1.2992 |
| Weight (kg) |
2.3 kg
|
Product Properties
| Bore |
C - Cylindrical Bore |
| Seal |
No Seal |
| Cage Type |
P - Plastic Molded Cage |
| External Modification |
No External Modification |
| Radial Internal Play |
Cn Normal Internal Play |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
Data from Schaeffler (medias)
| Raceway diameter inner ring (F w) mm |
82,5 |
| Width (b) mm |
33 |
| Radial Static Load Rating C0r (N) |
191000 |
| Radial Dynamic Load Rating Cr (N) |
214000 |
| Basic static load rating, radial (C 0r) |
"191000.0000" |
| Limiting speed (n G) |
6800 |
| Reference speed (n u03d1r) |
4800 |
| ECLASS number |
23-05-09-01 |
| ECLASS2 number |
23-05-09-01 |
| Medias description |
Cylindrical roller bearing RNU..-E-XL-TVP2, with cage, single row, non-locating bearing, 2 ribs on outer ring, no inner ring, type RNU |
Suffix description
| E |
Increased Load Capacity |
| XL |
X-Life |
| TVP2 |
Solid Window Cage Made From Glass Fibre Reinforced Polyamide PA66. Roller Riding |
