FAG QJ344-N2-MPA

FAG QJ344-N2-MPA
FAG QJ344-N2-MPA rulman resim 1
FAG QJ344-N2-MPA rulman resim 2
FAG QJ344-N2-MPA rulman resim 3
Price: 6,529.27 $
Specifications
Brand FAG
Item Number QJ344-N2-MPA FAG
Manufacturer Part Number 0192626710000
EAN 4012801593908
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 220
Outer (D) MM 460
Width (B) MM 88
Inner (d) Inch 8.6614
Outer (D) Inch 18.1102
Width (B) Inch 3.4646
Weight (kg) 71.9 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification N2 - 2 Locking Groove in Outer Ring
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 88
Radial Static Load Rating C0r (N) 1650000
Radial Dynamic Load Rating Cr (N) 900000
Basic static load rating, radial (C 0r) "1650000.0000"
Limiting speed (n G) 2430
Reference speed (n u03d1r) 1080
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ3..-N2-MPA, inner ring split
Suffix description
N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
MPA Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing)
