FAG QJ322-N2-MPA-T42A
Price: 1,104.64 $
Specifications
| Brand | FAG |
| Item Number | QJ322-N2-MPA-T42A FAG |
| Manufacturer Part Number | 0190052614381 |
| EAN | 4026677648839 |
| Category | Four Point Contact Ball Bearing |
| Inner (d) MM | 110 |
| Outer (D) MM | 240 |
| Width (B) MM | 50 |
| Inner (d) Inch | 4.3307 |
| Outer (D) Inch | 9.4488 |
| Width (B) Inch | 1.9685 |
| Weight (kg) | 11.83 kg |
| Seal | No Seal |
| Cage Type | MA - Brass Cage, Centered on Outer Ring |
| External Modification | N2 - 2 Locking Groove in Outer Ring |
| Radial Internal Play | C2 Internal Play (Less than Cn) |
| Precision | Special Axial Clearance |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Split inner ring |
| Width (b) mm | 50 |
| Radial Static Load Rating C0r (N) | 415000 |
| Radial Dynamic Load Rating Cr (N) | 345000 |
| Limiting speed (n G) | 4950 |
| Reference speed (n u03d1r) | 2700 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Four-point contact bearing QJ3..-N2-MPA, inner ring split |
| N2 | Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer |
| MPA | Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing) |
| T42A | Special Axial C2 Clearance |
