FAG 6322-Z

FAG 6322-Z
FAG 6322-Z rulman resim 1
FAG 6322-Z rulman resim 2
FAG 6322-Z rulman resim 3
FAG 6322-Z rulman resim 4
Price: 413.09 $
Specifications
Brand FAG
Item Number 6322-Z FAG
Manufacturer Part Number 0191118780000
EAN 4012801281546
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 110
Outer (D) MM 240
Width (B) MM 50
Inner (d) Inch 4.3307
Outer (D) Inch 9.4488
Width (B) Inch 1.9685
Weight (kg) 9.54 kg
Product Properties
Bore C - Cylindrical Bore
Seal Z - Steel Seal on One Side
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 50
Radial Static Load Rating C0r (N) 165000
Radial Dynamic Load Rating Cr (N) 201000
Basic static load rating, radial (C 0r) "165000.0000"
Limiting speed (n G) 3800
Reference speed (n u03d1r) 4150
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 63..-Z, single row, cf. DIN 625-1
Suffix description
Z Shield Of Pressed Sheet Steel On One Side Of The Bearing
