FAG QJ320-N2-MPA-C3 Image 2
Visual product photo and picture of the product.
Price: 625.57 $
Specifications
Weight and Dimensions
| Inner (d) MM |
100 |
| Outer (D) MM |
215 |
| Width (B) MM |
47 |
| Inner (d) Inch |
3.937 |
| Outer (D) Inch |
8.4646 |
| Width (B) Inch |
1.8504 |
| Weight (kg) |
9.1 kg
|
Product Properties
| Seal |
No Seal |
| Cage Type |
MA - Brass Cage, Centered on Outer Ring |
| External Modification |
N2 - 2 Locking Groove in Outer Ring |
| Radial Internal Play |
C3 Internal Play (Higher than Cn) |
| Precision |
Standard Precision |
| Heat Stabilization |
No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring |
Split inner ring |
Data from Schaeffler (medias)
| Width (b) mm |
47 |
| Radial Static Load Rating C0r (N) |
365000 |
| Radial Dynamic Load Rating Cr (N) |
325000 |
| Basic static load rating, radial (C 0r) |
"365000.0000" |
| Limiting speed (n G) |
5400 |
| Reference speed (n u03d1r) |
3000 |
| ECLASS number |
23-05-08-03 |
| ECLASS2 number |
23-05-08-03 |
| Medias description |
Four-point contact bearing QJ3..-N2-MPA, inner ring split |
Suffix description
| N2 |
Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer |
| MPA |
Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing) |
| C3 |
Internal Clearance Larger Than Normal |
