FAG QJ312-XL-MPA

FAG QJ312-XL-MPA
FAG QJ312-XL-MPA rulman resim 1
FAG QJ312-XL-MPA rulman resim 2
FAG QJ312-XL-MPA rulman resim 3
FAG QJ312-XL-MPA rulman resim 4
FAG QJ312-XL-MPA rulman resim 5
FAG QJ312-XL-MPA rulman resim 6
FAG QJ312-XL-MPA rulman resim 7
Price: 183.82 $
Specifications
Brand FAG
Item Number QJ312-XL-MPA FAG
Manufacturer Part Number 0190052530000
Also known as QJ312-MPA
EAN 4012801268196
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 60
Outer (D) MM 130
Width (B) MM 31
Inner (d) Inch 2.3622
Outer (D) Inch 5.1181
Width (B) Inch 1.2205
Weight (kg) 2.1 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 31
Radial Static Load Rating C0r (N) 126000
Radial Dynamic Load Rating Cr (N) 152000
Basic static load rating, radial (C 0r) "126000.0000"
Limiting speed (n G) 10400
Reference speed (n u03d1r) 4700
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ3..-XL-MPA, inner ring split
Suffix description
XL X-Life
MPA Solid Brass Cage
