FAG 6312-C-M-C4

FAG 6312-C-M-C4
FAG 6312-C-M-C4 rulman resim 1
FAG 6312-C-M-C4 rulman resim 2
FAG 6312-C-M-C4 rulman resim 3
FAG 6312-C-M-C4 rulman resim 4
Price: 165.17 $
Specifications
Brand FAG
Item Number 6312-C-M-C4 FAG
Manufacturer Part Number 0889794580040
Also known as 6312-M-C4
EAN 4054369496765
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 60
Outer (D) MM 130
Width (B) MM 31
Inner (d) Inch 2.3622
Outer (D) Inch 5.1181
Width (B) Inch 1.2205
Weight (kg) 2.09 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 31
Radial Static Load Rating C0r (N) 52000
Radial Dynamic Load Rating Cr (N) 89000
Basic static load rating, radial (C 0r) "52000.0000"
Limiting speed (n G) 10300
Reference speed (n u03d1r) 7400
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 63..-C-M, single row, cf. DIN 625-1
Suffix description
C Internal Design Modification
M Solid Brass Cage, Ball-Guided
C4 Bearing Internal Clearance Greater Than C3
