FAG QJ306-XL-MPA-C3

FAG QJ306-XL-MPA-C3
FAG QJ306-XL-MPA-C3 rulman resim 1
FAG QJ306-XL-MPA-C3 rulman resim 2
FAG QJ306-XL-MPA-C3 rulman resim 3
FAG QJ306-XL-MPA-C3 rulman resim 4
FAG QJ306-XL-MPA-C3 rulman resim 5
Price: 62.16 $
Specifications
Brand FAG
Item Number QJ306-XL-MPA-C3 FAG
Manufacturer Part Number 0167424430030
Also known as QJ306-MPA-C3
EAN 4012801180801
Category Four Point Contact Ball Bearing
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 72
Width (B) MM 19
Inner (d) Inch 1.1811
Outer (D) Inch 2.8346
Width (B) Inch 0.748
Weight (kg) 0.414 kg
Product Properties
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Split inner ring
Data from Schaeffler (medias)
Width (b) mm 19
Radial Static Load Rating C0r (N) 38500
Radial Dynamic Load Rating Cr (N) 57000
Basic static load rating, radial (C 0r) "38500.0000"
Limiting speed (n G) 19600
Reference speed (n u03d1r) 7800
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Four-point contact bearing QJ3..-XL-MPA, inner ring split
Suffix description
XL X-Life
MPA Solid Brass Cage
C3 Internal Clearance Larger Than Normal
